Linear guide made of V-Slot profiles

V-Slot profiles are used in many industries. The special design of V-Slot profiles allows for linear movement of the table equipped with V-Wheel castors. Depending on the model of the caster, this solution can be ideal for the construction of a simple slider, e. g. For photographic suite, building a 3D printer, CNC milling machine and many other machines.

How to build a basic linear guide from V-Slot profiles?

The V-Slot aluminium profile allows us to create many different designs. The use of OpenBuilds mounting plates allows you to create a component where the drive can be placed in different positions.

Below we will show you some examples of a linear guide made from OpenBuilds accessories.

This is the first article to launch a new series of tutorials! Let's go!

Laptop base v1

In this first article we will show you how using a CNC milling machine and V-SLOT profiles, you can create an interesting laptop stand at low cost. Of course, every laptop is different (it has different dimensions) so based on our design it is worth to check if your equipment will fit and possibly change the design to suit your needs.
